Ask the Expert |  How Can Speaker Design Affect Your Soundstage?

Ask the Expert | How Can Speaker Design Affect Your Soundstage?

1 comment

Would You Rather Sit in the Audience—or Feel Like You're on Stage?

It's a question we often consider when helping customers choose loudspeakers. Both experiences can be extraordinary, but they represent different approaches to reproducing music.

A great conventional loudspeaker can recreate the sensation of sitting in the audience at a live performance. The musicians appear before you, precisely positioned across a soundstage, with a convincing sense of depth, separation, and space.

But what if you want something different? What if you want to feel as though you're sitting among the musicians, surrounded by the performance rather than observing it?

Some loudspeaker designers pursue this immersive experience through technologies that change how sound radiates into the listening room.

One particularly interesting approach is the use of rear-firing drivers.

Why Does Sound Behind the Speaker Matter?

When we listen to live music, we don't hear only the direct sound coming from the instruments.

We also hear sound reflecting from the walls, ceiling, floor, and other surfaces. These reflections arrive at our ears slightly later than the direct sound, helping our brains interpret the size and character of the acoustic environment.

Consider the difference between hearing a violin in a small practice room and hearing that same violin in a concert hall. The instrument hasn't changed, but the acoustic environment dramatically alters our perception of the performance.

Most conventional box loudspeakers radiate their midrange and high-frequency energy primarily toward the listener. Although sound still reflects throughout the room, the speaker's radiation pattern determines how much energy reaches different surfaces.

Rear-firing drivers deliberately introduce additional energy behind the loudspeaker.

That sound reflects from the wall behind the speakers and returns to the listening area slightly later than the direct sound.

Our auditory system interprets the combination of direct and reflected energy as spatial information. When the balance is right, the soundstage can become wider, deeper, and more enveloping without sacrificing the clarity or placement of individual instruments.

The objective isn't simply to make the sound bigger. It's to make the acoustic space feel more believable.

Two Different Engineering Approaches

Two manufacturers that have embraced rearward radiation are Von Schweikert Audio and Audiovector, although their implementations are quite different.

Von Schweikert Audio has explored rearward sound radiation for decades through its Ambient Information Retrieval (AIR) technology.

Albert Von Schweikert's research examined how microphones capture spatial information and how loudspeakers interact with the listening environment during reproduction.

The company's designs use rear-mounted drivers to contribute additional ambient energy to the listening room.

For example, the VR.30 incorporates a rear-firing ribbon tweeter, while the larger ULTRA models employ more elaborate rearward-radiating arrays.

On models with adjustable ambient output, listeners can control the amount of rearward energy to suit their room and preferences.

This is particularly useful because a heavily furnished room with thick carpeting and substantial acoustic absorption behaves very differently from a room with hardwood floors, glass, and relatively bare walls.



The ability to adjust the ambient contribution allows the listener to find a balance between spaciousness, tonal coherence, and image focus.

Audiovector approaches the problem through its Soundstage Enhancement Concept (SEC).

In its R-series, Audiovector uses an Air Motion Transformer (AMT) tweeter architecture that permits radiation from both the front and rear of the driver.

Unlike a conventional dome tweeter mounted in a sealed enclosure, this arrangement allows some high-frequency energy to travel backward into the room.

Audiovector takes the concept further in models such as the R 6 Arreté, which incorporates a dedicated 3-inch rear-firing midrange driver with its own crossover.

This is an important distinction. Rather than relying exclusively on high-frequency ambience, Audiovector introduces controlled rearward energy into part of the midrange, where much of the character of voices and instruments resides.

The result can be a particularly convincing sense of depth and dimensionality, while maintaining the precise imaging expected from a high-performance loudspeaker.

Different Technologies, Similar Ambitions

Rear-firing drivers aren't the only way to create an immersive listening experience.

Ribbon-based designs, electrostatic panels, planar-magnetic loudspeakers, omnidirectional speakers, and open-baffle designs can all produce remarkably expansive presentations. Digital signal processing offers yet another approach.

For example, Raidho Acoustics uses proprietary ribbon tweeters with exceptionally wide horizontal dispersion to help create an expansive, three-dimensional soundstage without relying on dedicated rear-firing ambient drivers.

Other designs radiate sound both forward and backward, while omnidirectional loudspeakers distribute sound much more widely throughout the room.

Each technology introduces its own engineering challenges and compromises, but they share a common ambition: reproducing not just the instruments, but a convincing sense of the space surrounding them.

Setup: Getting the Most from Rear-Firing Drivers

This is where understanding the technology becomes especially valuable.

Because rear-firing drivers intentionally interact with the room, their performance depends on more than simply pointing the loudspeakers toward the listening position.

Distance from the wall behind the speakers

Moving a rear-radiating loudspeaker changes the path length traveled by reflected sound and therefore the timing of its arrival at the listener.

When speakers are positioned very close to the wall, rearward reflections return relatively quickly. Depending on their strength and frequency content, they can alter tonal balance and reduce the sense of separation between direct sound and ambience.

Moving the speakers farther into the room generally increases the reflection delay, potentially creating a more convincing sense of depth.

There isn't a universal minimum distance. The ideal position depends on the specific loudspeaker, the room, and the manufacturer's design recommendations.

Toe-in and speaker spacing

Toe-in—the angle at which speakers point toward the listening position—affects both direct sound and the distribution of reflected energy.

More toe-in can improve center-image focus in some systems, while less toe-in may create a broader presentation.

However, rear-firing designs don't all respond identically. Their front-driver dispersion patterns, rear-driver output, and crossover designs influence the result.

A useful approach is to begin with the manufacturer's recommended positioning, establish a stable center image, and then make small adjustments while listening for changes in width, depth, and tonal balance.

Room acoustics

The wall behind the speakers becomes a bigger part of the acoustic equation.

A large reflective surface may return more ambient energy than a wall covered with heavy curtains or absorptive treatment.

Interestingly, the objective isn't necessarily to eliminate those reflections. With a rear-radiating loudspeaker, some of that energy is intentional.

Excessive absorption directly behind the speaker can diminish the very spatial qualities the designer worked to create.

Conversely, a highly reflective room may produce too much reverberant energy, making images less distinct.

The goal is balance, not maximum reflection or maximum absorption.

Adjustable rear-driver output

When a speaker provides ambient-level adjustment, we generally recommend beginning conservatively.

Listen first for a stable vocal image and convincing instrumental placement. Then increase the rearward contribution gradually, paying attention to whether the soundstage becomes more natural and enveloping.

More ambience isn't automatically better.

The ideal setting is one where the soundstage opens up without individual performers becoming vague or artificially enlarged.

What Are the Trade-Offs?

Every loudspeaker design involves compromises, and rear-firing drivers are no exception.

Their greater interaction with the room can make setup more involved. Room boundaries, furnishings, and placement may have a stronger influence on the final presentation.

Reflected sound can also affect imaging. When the timing, frequency balance, or level of reflections isn't well controlled, the result may be spacious but less precisely focused.

This is why crossover design, driver selection, and the relationship between forward and rearward output are so important.

A properly engineered rear-firing system isn't simply a conventional loudspeaker with another tweeter attached to the back. It's a coordinated acoustic design.

And while additional reflected energy can create a compelling sense of immersion, the resulting presentation remains a combination of the recording and the acoustics of your listening room.

The Verdant Perspective

We love loudspeakers that create a beautifully defined performance in front of the listener. There's something extraordinary about hearing musicians precisely arranged across a soundstage, with convincing depth and separation.

But there's also something magical about a system that seems to make the room disappear, extending the musical experience around you.

Rear-firing drivers offer one fascinating way to achieve that sensation.

What makes the technology particularly compelling is that it doesn't necessarily require sacrificing imaging precision to gain spaciousness. When the engineering and setup are right, the two qualities can complement each other beautifully.

Ultimately, neither presentation is inherently better. They represent different priorities and different ways of connecting with music.

The question isn't simply how accurately a loudspeaker reproduces sound. It's how you want to experience the performance.

Would you rather sit in the audience—or feel like you're on stage?

Verdant Audio — Sound in Full Bloom.
